Polyester Screen

General Introduction of Polyester Screen for Printing Screen Application:

Our offers monofilament polyester screen (low-elongation) with a wide range of mesh counts and significant advantages compared with traditional polyester mesh.

Polyester was introduced to the screen printing market over 40 years ago and quickly replaced traditional silk as the fabric of choice among screen printers all over the world. It is a material that is uniquely suitable for screen printing because of its tensile strength, elastic memory and resistance to chemicals, abrasion heat and moisture. Polyester screen is a kind of synthetic fabric constructed similar to silk, yet with better uniformity. Compared to silk, polyester screen cloth offers extreme durability, yet has a lower price.

Common Mesh Counts of Polyester Screen: We provide polyester screen mesh for screen printing with a mesh variety of 60mesh/ inch, 80mesh, inch 100mesh/ inch, 110mesh/ inch,120mesh/ inch,135mesh/ inch,160mesh/ inch,180mesh/ inch,200mesh/ inch,230mesh/ inch,250mesh/ inch,280mesh/ inch,305mesh/ inch,355mesh/ inch,380mesh/ inch,420mesh/ inch.
Polyester screen cloth roll size:
Polyester Screen Max. width: 3200mm.


Detail Specification of Polyester Printing Mesh
model mesh
count
APERTURE  THREAD
DIAMETER
OPENING thickness INK THROUGH VOLUME
THEORETICALLY
mesh/inch micron micron % micron cm3/m2
72-45 180 92 45 40 68-76 33.1
72-48 180 90 48 36 75-84 33.1
72-55 180 81 55 30 88-97 26.6
80-45 200 75 45 36 65-74 27.7
80-48 200 72 48 33 75-84 28.7
90-48 230 56 48 25 77-85 23.5
100-40 250 58 40 33 62-71 21.3
110-40 280 48 40 27 65-71 18.4
110-34 280 54 34 35.5 52-57 20.2
0-34 305 45 34 30.5 52-57 18.4
140-34 355 31 34 19.5 56-62 14.4
150-31 380 36 31 29 43-47 13.1
150-34 380 30 34 20.5 56-62 14.9
165-31 420 31 31 23 52-58 12.88
